Flow 1 Step Thru

Flow 1 Step Thru

$479.99
$479.99 $479.99
Sale Sold out

SKU: 34173

Basic doesn't have to skimp on comfort, and simple doesn't mean devoid of features. The feature-laden Flow 1 combines ultimate comfort with ultimate affordability. An upright, see the cars and have the cars see you posture, suspension seatpost, and straightforward 7-speed-twist shifter make riding a bike as simple as... riding a bike.

Sizing Guide

SizeInchesCM
S / 15 ST
M / 17 ST

Color
Size

View full details

FEATURES

  • Upright ride positioning provides excellent visibility, comfort, and easy on/off the bike transitions
  • Mid-range, 1x7 drivetrain with twist shifter provides simple, easy shifting
  • Affordable price point keeps comfort within reach
  • Relaxed headtube angle provides more predictable and steady steering with nothing sneaking up on you
  • Relaxed seat tube angle brings the rider position less over the bars and more evenly positioned, with better posture

SPECIFICATIONS

FRAMESET
FrameFlow | Heat-treated 6061 aluminum | Newly Refined Design | Tig-welded construction | Easygoing geometry (pedal forward positioning) | Size-Specific Wheel Design | 68mm threaded BSA bottom bracket shell | 135mm quick-release spacing
ForkSteel | 1-1/8" threaded | Size-Specific Wheel Design | V-brake mount | 100mm quick-release spacing
ColorsBel Air Blue, Matte Dusty Lavender
DRIVETRAIN
Cranks3-piece | Forged alloy | Steel 38T chain ring with dual-guide design | 170mm length
PedalsFPD Causeway Flattopers | Shock-absorbing Kraton inserts
ChainKMC Z7 | 7-speed
Bottom Bracket68mm threaded BSA shell | JIS square taper | Sealed cartridge
Front DerailleurN/A
Rear DerailleurMicroshift M26 | 8s Long Cage | RD-M26L | SHIMANO COMPATIBLE
Derailleur ShifterMicroshift | 7s | Low Torque Twist Shifter | W Indicator | SHIMANO COMPATIBLE
Freewheel/CassetteShimano | 7-speed | Mid-range | 12-34T
WHEELS
TiresKenda Kwick Journey S: 26 x 1.75" M: 27.5 x 1.75"
Wheels/RimsAlloy | Width (internal): 19mm Double-wall | 32h
Front HubAlloy | 100mm quick release | Rim brake | 32h
Rear HubAlloy | 135mm quick release | Rim brake | 7-speed freehub | 32h
BRAKING SYSTEM
BrakesAlloy | V-brakes
Brake LeversAlloy | Linear Pull
OTHER COMPONENTS
Grips/TapeErgo Comfort | Dual Density
HandlebarSteel Riser Bar | Ø25.4 bar bore | 80mm rise | 15-degree wrist-saver sweep | 635mm width
StemQuill | Alloy | 30° rise | Ø25.4 bar bore | 80mm length
Headset1-1/8" integrated | threaded
SaddleHARO | Shock-absorbing
Seat PostSuspension | 27.2 x 300mm
Seat ClampAlloy | Quick release | Ø 31.8mm
ExtrasRack & Fender Mounts

GEOMETRY

Geometry frame chart
SIZES / 15 STM / 17 ST
A. Top Tube (Effective)572mm (22.5")588mm (23.1")
B. Seat Tube (C-T)381mm (15")432mm (17")
C. Standover Height430mm (16.9")445mm (17.5")
D. Head Tube Length190mm (7.5")200mm (7.9")
E. Head Angle68°68°
F. Seat Angle71°71°
G. Wheelbase1077mm (42.4")1097mm (43.2")
H. Chainstay440mm (17.3")450mm (17.7")
I. BB Drop40mm (1.6")55mm (2.2")
J. Stem Length
K. Bar Width635mm635mm
L. Crank Length170mm170mm
M. Wheel Size2627.5
